Pallet shuttle system is a semi-automated, high-density storage solution for storage of goods. Shuttle will automatically pick and retrieval pallets, cost-effective and time-saving. It removes the need for forklift to enter the aisles.
Based on the features of pallet shuttle, it could be combined with mover,stacker, WMS etc. The system can be turned into small and medium sized shuttle warehouse system.
Specification of Pallet Shuttle
|
Product Name: |
Pallet Shuttle/Radio Shuttle |
|
Running Speed: |
0.8-1.2m/s |
|
Load Capacity: |
0-1500kg |
|
Working Temperature: |
CT: -30-0°C ST: 0-45°C |
|
Power Supply: |
Lithium Battery |
|
Battery Charging Time: |
2-3 hours |
|
Battery Working Time |
8-10 hours |
|
Pallet Size: |
Standard Pallet Available, Customization for Special Size |
|
Controlling System: |
Remote Control, WIFI Control Customized |
|
Lifting Height |
220mm |
|
Warranty Period: |
1 Year |
|
Certification: |
CE, ISO9001 |
Why choose pallet shuttle racking system
- Simple and easy operation
- High space utilization, compared with conventional racking system, improve from 40% to 80%
- Automatic order picking efficiency doubled or tripled compared to drive in system
How Does Shuttle Pallet Racking Work
Shuttle Pallet Racking is a semi-automated storage system that uses shuttle carts to move pallets within the racks. Here's how it works:
A forklift places pallets at the start of the lane.
The shuttle cart moves the pallets to the first empty spot in the lane.
Once a pallet is placed, the shuttle returns to the start, ready for the next pallet.
To pick pallets, the shuttle moves them to the front of the lane, where a forklift picks them up.
This system can work with FIFO (First In, First Out) or LIFO (Last In, First Out), but LIFO is more common since only one end of the aisle is used for loading and unloading.
For FIFO, the forklift must be able to access the end of the lane to get the first pallet.
Advantage
● Cost-effective and time-saving, it removes the need for forklift to enter the aisles.e
● No requiring the use of special forklifts
● Low level of risks or damage to the equipment and operating staff
● Fast and sustainable;
● Automatically handles pallet picking and retrieval
● Offers more effective, high-density storage
● Can pick up, deposit and re-organize pallets with great precision
● Available in different models designed for various pallet configurations
Applicable products & industry
Shuttle racking system is suitable for below product types substantial decline on labor cost with big production batch and high input & output frequency.
Shuttle racking suitable for below industries
Cold chain industry, Food beverage industry, Liquor industry, Pharmaceutical industry, Logistics industry, Commodity industry, FMCG industry, Paper industry, Packaging industry, Fresh fruits & vegetables industry, Chemical industry.
Components of the Shuttle Pallet Racking System
The Pallet Shuttle Racking system has a basic structure made up of frames and beams, all built with the quality of Maxrac's racking solutions.
The system also includes key components for its semi-automatic operation, such as the shuttles and rails they move on. Safety accessories are added to ensure the structure and pallets are secure.
We can divide the main components into two categories:
- Metal structure – Frames and beams that make up the racking system.
- Shuttles – The carts that move pallets along the rails.
